MUSTOOL MT8206 User Manual

31
Features of digital multimeter
All range uncertainty is expressed in ± (a% reading + unit). The calibration interval is one year.
Environmental conditions for guaranteed uncertainty: 23 ° C ± 5 ° C, < 75% RH.
Analog Bandwidth
ACV/DCV/ACA/DCA 20kHz
Maximum Real-Time Sampling Rate
200ksps
Features
Range
Resolution
Uncertainty
DC voltage
400mV
0.1mV
 (0.75%rdg + 10dgt)
 (1.5%rdg + 10dgt)/1000V
4V/40V/400V/1000V
1mV/10mV/100mV/1V
AC voltage
400mV/4V/40V/400V/750V
0.1mV/1mV/10mV/100mV/
1V
50Hz~400Hz

(1.0%rdg + 10dgt)
400Hz~20kHz (not checked
above 20kHz)

(5.0%rdg + 10dgt)
50Hz~400Hz/750V

(1.5%rdg + 10dgt)
DCA
40mA /400mA
10µA /100µA

(1.2%rdg + 10dgt)
4A/10A
1mA/10mA
ACA
40mA /400mA
10µA /100µA
 (1.5%rdg + 10dgt)
