32
50Hz~5kHz (not checked
above 5kHz)
4A/10A
1mA/10mA
Resistance
400/4K/40K/400K/
4M/40M
0.1Ω/1/10/100/1K/
10k
 (1.0%rdg + 5dgt)
 (3.0%rdg + 5dgt)/40M
Capacitance
51.2nF/512nF/5.12μF/51.2μF/
100μF
10pF/100pF/1nF/10nF/100nF

(2%rdg + 10dgt)/51.2nF

(1%rdg + 3dgt)
10mF
1μF
 (5%rdg + 3dgt)
Frequency
5Hz~5MHz
1Hz

(1.0%rdg + 5dgt)，(Signal
amplitude not less than
2Vp-p, AC V, MAX380V)
Diode test
Open circuit voltage: about 1.5 V, maximum test current: about 1.5mA
Continuity test
Reference resistance: about 50Ω
Fuse specification
500mA/250V ,10A/250V
