VJ-1638/1638W OPERATION MANUAL ERRATA
October 2012
VJ1638xE-A-01c 9 MUTOH INDUSTRIES LTD.
8. Press the [Enter] key on the operation panel.
The printing of following items starts.
Color Patches
Media Type
Preset Heater Temperature
・Preset Pre Heater Temperature
・Preset Platen Heater Temperature
・Preset Dryer Temperature
Head Temperature Information
NOTE
Do not open the covers or move media loading lever during printing.
User Type = Type 3 Head Temp. =25˚CPre Heater = 42˚C
Praten Heater = 42˚C
Dryer = 42˚C
dE(94) < 1.0: No discernable difference in color.
dE(94) < 3.2: Minimally discernable color difference for colors viewed side-by-side.
dE(94) < 3.2: Minimally discernable color difference for colors in close proximity, not side-by-side.
2
1
3 4
No. Name
1 Color Patches
2 Media Type
3 Preset Heater Temperature
4 Head Temperature Information
・ After printing is complete, "Attaching instrument [ENTER]" is displayed on the operation
panel.
To Next Page
