VJ-1638/1638W OPERATION MANUAL ERRATA
October 2012
VJ1638xE-A-01c 10 MUTOH INDUSTRIES LTD.
9. Press the [Enter] key.
"Wait for a while..." is displayed on the operation panel.
The print head moves to the left.
"Open left mainte. cover." is displayed on the operation panel.
10. Open the maintenance cover on the left of the printer.
"Remove connector cap and attach instrument [ENTER]" is displayed on the operation
panel.
1
No. Name
1 Maintenance cover
NOTE
When a certain time has passed without opening the maintenance cover, the print head returns toward
the right side of the printer to protect the print head. "Attaching instrument [ENTER]" is displayed. Restart
from the Step 8.
To Next Page
