76 List of specifications
List of specifications
Model name VJ-628
Print method On demand piezo method
Drive method Firmware servo/DC motor drive
Paper feed method Horizontal conveyance, roll paper, set from the back of the
product, front discharge paper with paper feed operation,
limited to outward roll
Media fix Pressure roller down method with manual media fixing knob
Conditions of usable
media
Roll paper peripheral 150 mm
Roll paper weight 9 kg or less
Maximum paper width 630 mm (In case of paper tube > paper width, paper tube
width)
Maximum paper thickness Head height when set to “Low”: 0.3 mm Max.
Head height when set to “High”: 1.3 mm Max.
Maximum print width 620 mm
Media cut method Auto cut or manual cut
Heater Installed under the media guide, OFF/30 °C to 45 °C
Head height
adjustment
2 levels, Low and High
CPU 64 bit RISC CPU
Memory 256 MB
Interface Ethernet(10/100BASE-TX)
Ink Color 4 colors (Black, Cyan, Magenta, Yellow)
6 colors (Black, Cyan, Magenta, Yellow, Light Cyan, Light
Magenta)
Type 220 ml cartridge
Waste ink tank Fixed to the body type, capacity 1500 ml, waste ink discharge
by users
Environmental
conditions
Operating environment Temperature 20 to 32 °C, humidity 40 to 60 %,
no condensation.
Ranges to ensure printing
precision
Temperature 22 to 30 °C, humidity 40 to 60 %,
no condensation.
Change rate Temperature: No more than 2 °C per 1 hour
Humidity: No more than 5 % per 1 hour
Environment for storage • If not charged with ink when stored: up to 6 months
Temperature -20 to +60 °C, humidity 20 to 80 %.
• If charged with ink when stored: up to 1 week*
Temperature -10 to +40 °C, humidity 20 to 80 %.
*Up to 4 days if the ambient temperature is 32 °C or higher.
