MV Agusta F4 SPR - Topping up the Coolant Level

- 111 -
MAINTENANCE 6
6
6.6. Checking the coolant level
Check the coolant level while the engine is off and cold.
The check must be performed after placing the motorcy-
cle in an upright position on a horizontal surface.
Ensure that the coolant level is between the MIN mark
and the lower side of the frame tube as shown in the
figure.
If the coolant level is below the MIN mark, top up the
coolant as described at paragraph 6.6.1.
WARNING
Do not start the engine if the coolant level is
below the MIN mark.
