ADJUSTMENTS 5
5
5.7.1. Spring preload
The adjustment is obtained from the standard
position, which is found by fully turning the adju-
sting nut counterclockwise and then clockwise
(see table). Rotate clockwise to increase the
spring preload or counterclockwise to decrease it.
5.7.2. Rebound damper (front suspension)
The adjustment is obtained from the standard
position, which is found by fully turning the screw
clockwise and then counterclockwise (see table).
Rotate clockwise to increase the damping action
or counterclockwise to decrease it.
