- 90 -
ADJUSTMENTS 5
5
5.7.3. Compression damper (front suspension)
The adjustment is obtained from the standard position,
which is found by fully turning the screw clockwise and
then counterclockwise (see table). Rotate clockwise to
increase the damping action or counterclockwise to
decrease it.
5.8. Adjusting the rear suspension
CAUTION
When you estimate
the rear suspen-
sion settings, never
push or pull in any
way on the exhaust
mufflers. They
would be certainly
damaged.
NO NO
