- 153 -
TECHNICAL INFORMATION 8
8
8.1.2. Rear brake circuit
1 Brake lever
2 Brake master cylinder
3 Brake line
4 Brake fluid reservoir
5 Brake caliper
6 Brake disc
4
6
1
2
3
5
