- 92 -
ADJUSTMENTS 5
5
5.8.1. Rebound damper (rear suspension)
The adjustment is obtained from the standard position, which is
found by fully rotating the ring clockwise and then counter-
clokwise (see table). Rotate clockwise to increase the damping
action or counterclockwise to decrease it.
5.8.2. High speed compression damper (rear suspension)
The adjustment is obtained from the standard position, which is
found by fully rotating the screw counterclockwise and then
clockwise (see table). Rotate clockwise to increase the damping
action or counterclockwise to decrease it.
5.8.3. Low speed compression damper (rear suspension)
The adjustment is obtained from the standard position, which is
found by fully rotating the screw clockwise and then counter-
clockwise (see table). Rotate clockwise to increase the damping
action or counterclockwise to decrease it.
