- 159 -
TECHNICAL INFORMATION 8
8
Dry weight (kg) 188
Fuel tank capacity (lt) (*) 21
Reserve fuel (lt) (*) 4
Oil in crankcase (kg) 3.5
ENGINE
Type Four-cylinder, four-stroke, 16 valves
Bore (mm) 73.8
Stroke (mm) 43.8
Total displacement (cm
3
) 749.4
Compression ratio 13 : 1
Starting Electric starter
Cooling system Liquid cooling with water-oil heat exchanger
Crankcase and covers die-cast
Head and cylinders chill-cast
Valves bimetal / single-metal
VALVE TRAIN
Type Double-overhead camshaft, radial valves
LUBRICATION
Type Wet sump
Specifications
* : The indicated data must not be intended as binding informations. They can change according to the environmental tempe-
rature, the engine temperature and the evaporation point of the gasoline.
