- 161 -
TECHNICAL INFORMATION 8
8
Specifications
Fourth gear 1.58 (6.71) 1.58 (6.87) 1.58 (7.06)
Fifth gear 1.43 (6.07) 1.43 (6.22) 1.43 (6.39)
Sixth gear 1.33 (5.65) 1.33 (5.79) 1.33 (5.95)
FRAME
Type CrMo steel tubular trellis (TIG welded)
Swingarm pivot plates Aluminium alloy
FRONT SUSPENSION
Type “Upside down” telescopic hydraulic fork with
rebound-compression damping and spring preload adjustment
Rod diameter (mm) 50 with Titanium Nitride treatment
Travel on leg axis (mm) 118
REAR SUSPENSION
Type Progressive, single shock absorber with rebound-compression
(high speed/low speed) damping and spring preload adjustment
Swingarm Aluminium alloy
Wheel travel (mm) 120
FRONT BRAKE
Type Double steel floating disc
Disc diameter (mm) 310
Disc flange Aluminium
Calipers, piston diameters (mm) 6-piston Ø 22.65; Ø 25.4; Ø 30.23
