17 -
GENERAL INFORMATION 1
1
1. - Front fairing;
2. - Left-hand rearview mirror;
3. - Right-hand rearview mirror;
4. - Air box;
5. - Fuel tank;
6. - Tail section;
7. - Fuel tank left-hand side fairing;
8. - Fuel tank right-hand side fairing;
9. - Left-hand side fairing;
10.- Right-hand side fairing;
11.- Undercowl:
Black Painting - CRC 1951-6
(Code PPG ∗0036/1 + Code PPG ∗0036/2)
Bodywork parts reference colours
Bodywork parts are painted with the following reference colours:
