hyperion X5 2D/3D - TECHNICAL MANUAL
EN
CONTROL BOARDS DESCRIPTION
5.4.1 CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 Sensor synchronisation / supply from LOGIC
K2 24V DC Panel supply
K3 Sensor synchronisation
5.4.2 LEDS LIST
LED ID DESCRIPTION
DL1 (VIN) 48V from LOGIC board
DL2 (VCC) Analog 5V towards sensor
DL3 (VDD) Digital 5V towards sensor
