46
EN
hyperion X5 2D/3D - TECHNICAL MANUAL
EN
CONTROL BOARDS DESCRIPTION
5.6 KEYBOARD BOARD 97661484
5.6.1 CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 Keyboard signals from LOGIC
5.7 LOGO BOARD 97661539
5.7.1 CONNECTORS LIST
CONNECTOR DESCRIPTION
K1 24V power supply fron Logic board
