CONTROL BOARDS DESCRIPTION
PIN 5-6: not used
5.3 LOGIC BOARD 97661408
5.3.1 CONNECTORS LIST
CONNECTOR DESCRIPTION
K10 Ethernet connection to PC
K3 Powe supply and sync signal for sensor interface card.
K41 Chinrest microswitch
K1 Power supply input from powe board
K39 24V power supply toward engraved logo light
K26 K23 Monobloc lasers
K24 Chin rest lasers
K2 Collimator motor
K8 Y axis motor
K14 R axis motor
K5 Collimator photocell
K9 Y axis photocell
K15 R axis photocell
K16 Keyboard signals connector
K13 CAN connector to power board
K4 Not used
K31 Serial port, not used
K29 Not used
5.3.2 DIP SWITCHES LIST
DIP Switches DESCRIPTION
SW4 Not used, all OFF
SW2 Reboot button
SW3 Factory reset switch
5.3.3 LEDS LIST
LED ID COLOR NAME ON BOARD DESCRIPTION
DL1 YELLOW CAN ACT
CAN activity. Normally on ashing. On steady or off in case of CAN
error condition.
DL2 RED ERR
Error status, normally off. Flashing upon startup, the number of ashes
represents the FW version. When ERR is on the number of ashes from
CPU LED represents the error code.
DL3 GREEN CPU
Normally ashing at 1Hz (10Hz during column movement or x-ray
emission). When ERR is on the number of ashes from CPU LED
represents the error code.
DL4 GREEN MOTORS Motors enabled, normally on.
DL5 GREEN SYNC_PAN Logic-sensor sync signal, normally off
DL7 GREEN MOTX Not Used
DL8 GREEN MOTY
On if Y motor is active. If ashing the motor is in error (disconnected,
short-circuit, overheating, broken driver)
DL9 GREEN MOTC Not used
