N-Com B902 - Applying the ESS System to the Helmet

EN
12
3.2. Adjusting the microphone
The B902 system makes it possible to adjust the position of the microphone in order to facilitate its
positioning in the different helmet models.
Proceed as follows:
• Open the clip positioned on the microphone boom, operating as indicated in Fig. 21.
• Adjust the microphone (Fig. 22).
• Close the clip (Fig. 23).
Fig. 21
Fig. 22
Fig. 23
To ensure good voice transmission quality, it is recommended to position the microphone sponge at
the side of your mouth.
3.3. Removing the B902 system from the helmet
Fig. 24
• Remove the cheek padding and the shell
gasket.
• Remove the keypad from the shell, as shown
in Fig. 24.
FOR N87 – N100-5 HELMENTS ONLY – removing the keypad
• Remove the keypad from the shell, as indicated in Fig. 25.
• Rotate the keypad in a counterclockwise direction (Fig. 26).
• Remove the cheek padding and the shell gasket.
Fig. 25 Fig. 26
