PPA55xx Quick User Guide
Page 102
*WARNING: Remember to connect either the Internal or External shunt
only to the PPA55xx*
WR5000
Wideband Rogowski
Transducer
On
Fault
OFF
5KA (0.4mv/a)
1KA (2.0mv/a)
BNC
DC Input
15 Way Connector
BNC – BNC safety lead
