Nabco GT 710 Installation Manual

11 of 26
www.NabcoEntrances.com GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide
Rev 12-20-17 P/N C-00178




 

Full Rod Length
Rod Length - minus 1”
DN 1739
Center Eye
of Link
Cut Mark
Figure 13 Measure Rod Length
SECTION 53: Secure the Arm Shoe to the Door


DN 1931
Arm Shoe
Sex Bolt
1/4-20 x 2-1/4”
Phillips Head Screw
Figure 14 Secure Arm Shoe to the Swing Door







DN 1097
Threaded Rod
Color Coordinated Sleeve
Figure 15 Secure Arm Shoe to the Swing Door
