Nabco GT 710 Installation Manual


www.NabcoEntrances.com GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide
Rev 12-20-17 P/N C-00178

Header
Shim
Wall
Top of Door Frame
Swing Door
GT 710 SIDE LOAD SWING DOOR
GT 8710 SIDE LOAD SWING DOOR
Header
Shim
Wall
Top of Door Frame
Swing Door
DN 1080
Figure 7 Shim between Conversion Unit and Wall
SECTION 44: Secure the Header to the Door Frame



DN 1132
1/4” Screw holes
Flush Header to
Pivot Door Jamb
(or 1-3/4” Ver cal Line)
ON
1413121110
98
7
6
54
321
Figure 8 Secure Header to Door Frame
SECTION 45: Ensure Proper Spindle Locaon
Aenon: Adjustments to the locaon of Motor/Operator must be made if the distance between the “center of
spindle” and “edge of Jamb Tube” is dierent from the measurement shown within this secon
451 Outswing Bu Hinge
DN 1932
6-1/2”
Bu Hinge
Outswing
1-3/4”
Header
Overlap
ON
1413121110
98
7
6
54
321

Nabco GT 710 Specifications

General

Brand	Nabco
Model	GT 710
Category	Gate Opener
Language	English
