www.NabcoEntrances.com GT 710-8710 OPUS Low Energy Swing Doors Quick Set-Up and Parts Guide
Rev 12-20-17 P/N C-00178
ON
1413121110
98
7
6
54
321
DN 1088
Dim B = Bu Hinge
B
3/8” Sex Bolt holes
1-11/16”
C
Dim C = Center Pivot
Face of Swing Door
Back of Header
Dim A =
Reveal
A
Figure 16 Measure to Mark the First Sex Bolt Hole used to secure the Track
SECTION 62: Prepare the Swing Door for a Track with Zero Reveal
Note: For zero Reveal applicaons, the Straight Arm can be used to eliminate the L-Shape Arm from protruding into the room.
X Straight Arm:
X L-Shape Arm:
DN 1374
Straight Arm
w/zero Reveal = 11/16”
L-Shape Arm
w/zero Reveal = 1-11/16”
3/8” Sex Bolt holes
ON
1413121110
98
7
6
54
321
Figure 17 Zero Reveal
SECTION 63: Secure the Track to the Door
To Next Page
