Nabco GYRO TECH Nabco Multi-Module - Mode 2 - Apartment or Access Control Diagram - Magnum 4 Control

Page 11 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 2 - APARTMENT OR ACCESS CONTROL DIAGRAM - MAGNUM 4 CONTROL
Interior Switch
Unlocks and opens door
Normally Open - Dry Contacts
Exterior Switch
(Only active when someone "buzzes
down") Switch opens door.
Normally Open - Dry Contacts
ELECTRIC
STRIKE
TVS
iti-200S
RELAY2RELAY1
WET3WET2
DRY2DRY1
DRY
COMCOM
WET
WET1N.O. COM N.C.N.C.COMN.O.
12V24V
LED LED
RL2RL1
RELAY 1
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 2
ON TIME
SW 1
MODE
SWITCH
DN 0302
BROWN
BLACK
RED
WHITE
VIOLET
ORANGE
1
2
3
4
5
6
If magnetic
lock or fail safe
strike used,
connect lock
wires to COM
and N.C.
terminals of
Multi-Module
STRIKE POWER
(To match strike
voltage)
Terminal Strip on
Magnum Control
Apartment
Interphone Panel
(Powered
Signal)
Unlocks door
only
EXISTING LOCK POWER
Not polarity sensitive.
Voltage Suppressor
directly to strike.
(supplied)
Connect Transient
