Page 20 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 6 - WASHROOM CONTROL RELAY DIAGRAM - ANALOG CONTROL
Not polarity sensitive.
Voltage Suppressor
directly to strike.
(supplied)
Connect Transient
24 VAC120 VAC
Transformer
P/N 14-2101
24 VAC
Fail Safe
Optional Occupied Light
TVS
STRIKE
ELECTRIC
STRIKE POWER
(To match
strike voltage)
Push to Lock Switch
Contacts close when door is closed
Connect to COM and N.O. terminals on switch.
Magnetic Door Position Switch
P/N 14-11313
Exterior Push Plate
Normally Open - Dry Contacts
Interior Push Plate
Normally Open - Dry Contacts
DN 0302
SW 1
MODE
SWITCH
RELAY 2
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 1
ON TIME
RL1 RL2
LEDLED
24V 12V
N.O. COM N.C. N.C.COMN.O. WET1
WET
COM COM
DRY
DRY1 DRY2
WET2 WET3
RELAY1 RELAY2
iti-200S
NOTES:
1. Fail Safe Strike Used
2. A black circle indicates a
wire connection.
3. Power supply inputs not
polarity sensitive.
Activation Connector on Analog Control
BLACK
RED
To Next Page
