Page 12 www.NabcoEntrances.com 5-7-10
Nabco Multi-Module
MODE 2 - APARTMENT OR ACCESS CONTROL DIAGRAM - ANALOG CONTROL
Transformer
P/N 14-2101
24 VAC
24 VAC120 VAC
STRIKE POWER
(To match strike
voltage)
If magnetic
lock or fail safe
strike used,
connect lock
wires to COM
and N.C.
terminals of
Multi-Module
DN 0302
SW 1
MODE
SWITCH
RELAY 2
ON TIME
DOO
(DELAY
ON
OPERATE)
RELAY 2
RELAY 1
ON TIME
RL1 RL2
LEDLED
24V 12V
N.O. COM N.C. N.C.COMN.O. WET1
WET
COM COM
DRY
DRY1 DRY2
WET2 WET3
RELAY1 RELAY2
iti-200S
TVS
STRIKE
ELECTRIC
(Powered
Signal)
Unlocks door
only
EXISTING LOCK POWER
Activation Connector on Analog Control
BLACK
RED
Apartment
Interphone Panel
Connect Transient
(supplied)
directly to strike.
Voltage Suppressor
Not polarity sensitive.
Exterior Switch
(Only active when someone "buzzes
down") Switch opens door.
Normally Open - Dry Contacts
Interior Switch
Unlocks and opens door
Normally Open - Dry Contacts
To Next Page
