Nabco Multi-Module
Size 3 1/4" x 2 1/4" x 3/4"
Mounting Double sided foam tape
Operating voltage 12/24 volts Ac or Dc
Current Draw 18 mA Standby, 40 mA Max.
Inputs
2 - dry contacts
3 - wet inputs
12-24 VAC or DC, optically isolated, non-polarity sensitive
Outputs 2 - form C (SPDT)
Relay contact rating
4 amps @ 30VDC
Time delays
Relay 1 on time - 0.5-30 sec.
Delay on operate Relay 2 - 1-30 sec
Relay 2 on time - 0.5-30 sec.
To protect the Multi-Module from voltage spikes, please use
the provided transient voltage suppressor
P/N 11-12242 Multi-Module Assembly
QTY PART NO. DESCRIPTION
1 14-12240 Multi-Module & Voltage Suppressor
1 15-12241 Multi-Module Installation Manual
1 14-11313 Magnetic Switch Assembly
1 14-6284-03 Plastic Bag
1 14-2243 Label
