Nabco U30 User Manual

Rev. 3-12-13 Part #15-9000-30
www.NabcoEntrances.com U30 Microprocessor Control
5-19 Adjustment Procedures
Special Funcon Adjustment
Adjustment Descripon
...Recycle connued ● Motor Rotaon funcon is set to N, counterclockwise. Select Y for the opposite hand,
clockwise rotaon.
● RECYCLE funcon is automacally set to always reopen the door if it strikes an object during
the closing cycle.
Recycle Sensivity Message will read: RECYCLE SENS. 1
● Adjusts how hard the door will push against an object before it recycles.
● The following (4) opons are available:
Zero DO NOT USE THIS SETTING!
One So
Two Medium
Three Hard
Aer Recycle Message will read: AFTER RECYCLE Y
Adjusts for operaon aer the Slide door reaches the full open posion caused by a recycle.
Y Closes Slide door aer the me delay expires.
N Keeps Slide door in the open posion; it will take another acvang signal for it to close.
Auxiliary Output 1
then: Output Timer 1
Message will read: AUX. OUTPUT 0
● Output mer 1 selecon is required only when selecng 0 or 2 on the Auxiliary output 1.
● Determines when the internal form C relay connected to OUT A (Normally Open) or OUT B
(Normally Closed) and OUT C (Common) terminals is picked.
● This internal relay is used for the operaon of an electric lock or to signal another controller,
relay or other device.
●If Zero is chosen, the next message will read OUTPUT TIMER 3. This opon has(4) sub-opons:
Zero Message will read: AUX. OUTPUT 0
Enables operaon of the electric lock and sets the me delay between release of the
lock and door movement.
Upon acvaon, the internal relay closes via the “OUT A” or “OUT B” and “OUT C” wires
for the operaon of the electric lock. Then, according to the seng of OUTPUT
TIMER below, the door will begin opening.
If Zero is chosen, the next message will read OUTPUT TIMER 3.This opon has four sub-
opons:
Zero 1/4
second
For Magnec Locks:
One 1/2
second
● The selected Time Delay for Lock Release is also used for Time
Delay to set the lock aer the Slide door reaches the Fully closed
posion.
Two 1 second
● (1) second is recommended for Magnec Locks.
Three 1 second For Electric Strikes:
● Will engage or disengage a jammed lock up to 10 mes before an
error message reads “Error_4”.
