Nabco U30 User Manual

Inial Startup 4-12
U30 Microprocessor Control www.NabcoEntrances.com
Part #15-9000-30 Rev. 3-12-13
Secon 4d: Inializaon of the Handy Terminal Display
After the Handy Terminal is plugged into the Terminal Connector it is automatically turned ON. The
Slide door will slowly close if it is not already closed.
a. GYRO TECH HANDY TERMINAL message will be displayed.
b. 
Press the Shift buttons to select:
X Y (Yes) to hear audible feedback after each menu button is pressed.
X N (No) to not hear audible feedback after each menu button is pressed.
Press ENTRY.
Secon 4e: Disconnecng the Handy Terminal
Wait at least (10) seconds before disconnecting the Handy Terminal to allow the:
X Last Test to complete
X Message Display to stabilize
Disconnect the Handy Terminal by sliding the metal jacket off the Terminal Connector before
removing the Handy Terminal cable.
a. If power to the U30 Microprocessor Control needs to be disconnected, wait an additional (10)
seconds to ensure all settings have been established. Please see .
Slide back the metal sleeve FIRST and keep it pulled back while disconnecting the
Cable plug from the Terminal Harness. Failure to do so will cause damage to both
the Cable and Terminal Harness.
Section 4f: Determine Correct Handing
With power off, manually slide the door open half way.
Turn power ON. The Slide door should slowly close (per Power On factory settings).
If the Slide door slowly Opens it was set up with the wrong Hand. In that event the U30
Microprocessor Control 
of the door. This is done by changing the setting of “RECYCLE” with the Handy Terminal. To do this:

Press ENTRY until the screen displays SPECIAL FUNCTION ADJUSTMENTS. Select YES.
Continue pressing ENTRY until the Screen displays RECYCLE. Change the setting.
Disconnect the Handy Terminal.

Plug the Handy Terminal back into the Terminal Connector.
Secon 4g: Seng the Stroke of the Slide Door
1. SLIDE/SWING/STRK Y N message will be displayed.
ENTRY.
3. SWING DOOR Y N message will be displayed.
ENTRY.
5. FULL OPEN POINT PRESS TEST message will be displayed.
Manually slide the door to full open. Press TEST.
a. The Slide door will slowly close while measuring the Stroke of the door.
7. STD FUNCTION Y N message will be displayed after the initial Stroke setup is completed.
CAUTION
