NACD IPVIEW - System Installation Diagram; Apartment Wiring

1 System Installation Diagram
1.1 Apartment Wiring Diagram
1.2 High Level Wiring Diagram
Note: Optional for POE function Outdoor station does not need an extra power
supply when with built-in POE function.
System Diagram With PoE
5
Black (GND)
Red(DC+12V)
12V
GND
NETWORK
NC
COM
NO
CTL
GND
DET
RST
(Red)
(Yellow)
(Green)
Family2
Family3
Family4
RJ-45
(Black)
(White)
Button
Door magnetic
detection
RJ-45
Family1
1 2
lock
1 2
101
201
301
401
power
3
