Nacra F16 - Spin Tack System

NACRA EMPOWERING SAILORS SINS 1975
1.9 Spin tack system
1. Mount the tack-releaseline. Tie a gure
8 knot on the port side underneath the
trampoline. Aach the ring 4x 25 at the
other end on the starboard side under-
neath the trampoline.
2. Feed one end of the tackline through the
block located underneath the front cross-
bar next to the mastpin. Then lead the
tackline through the ring, the cleat and the
16mm block next to the cleat.
3. Aer the 16mm block use the grommet
on the starboard side of the trampoline
4. Tie the tackline shockcord to the end of
the tackline and lead the shockcord
through the grommet on the starboard
side of the trampoline
5. Take the other end of the tackline shock-
cord and use the small grommet in the
middle of the V-bar to exit. Tie a loop in
the shockcord. This loop will be used to
e onto the middle of the spinsheet.
Note:
The F18 infusion and Carbon 20 has the tackline
guided by a 29mm carbo block aached on the
staymaster.
