Nacra F16 - 3 Rudders

NACRA EMPOWERING SAILORS SINS 1975
3. rUDDERS
1. Assemble the upper and lower casng on
the rudderblade. Use a at screwdriver
2. Use the self locking slot for the nylock nut at the port
side of the casngs!
3. Put the boat on high support or a
trailer to allign the rudders. High
enough to lock down the rudders
7. Measure the length between the middle of
the rudders at the back and front of the
rudders. Measure at the same horizontal level!
8. The rudders must face 2 mm inwards, this is
adjustable by changing the rod length.
9. Check if the rod lenght is the same at both
sides before you screw in the phillipscrew.
5. Take the Philips screw out of the llerarm.
6. Place the ller extension in between the arms
check if the connector for the joysck is on
top!!
Rod
lenght
10. Fix the sliding bolt for the kick up tension, with the
rudder locked in. Push the bolt forward and x the bolt
while you’re sll pushing forward. Use two 7/16 wren-
ches.
11. Finally check the bolt of the eye screw of the lower
casng. The bolt must be xed by pung the nut on
tension. Use a 9/16 wrench. This bolt is also used to ad-
just the rudder rake.
Tools needed:
- at screwdriver
- philips screwdriver
- 7/16 wrench 2x
- 9/16 wrench
