10
1. Mount the bridle wires, stay adjuster and
compression pole on the bridle connec-
on ng.
Use the clevis pins 1/2 x 1/4
2. Adjust the ring 3x20 ss under the bridle
on each side as shown in the picture.
3. Place the mast with care on the trampoline with
the masrack down, support the back of the
mast to prevent it from scratching!
4. Check if the rigging and the shackles are
connected on the mast as have shown in the
manual.
5. Aach the schrouds to the staymaster to the
staymaster use the clevispin 1/4 x 5/8 WL .
Make sure the staymaster is at his maximum
length:10!
6. Aach the adjustable trapeze to the trapeze
wires. Check page ...how to assemble the sys-
tem.
7. Tie the adjustable trapeze wire to the trapeze
shockcords.
Check if the shrouds and trapeze wires are in
the right order before raising the mast!!
4. Rigging
4.1 preparation
Note: The F18 Infusion has no compressi-
on pole and bridle connecon ng but
a spi pole holder ring.
