NAD C 325BEE - Page 29

J3, J7, J28, J29, J38, J42,
J46, J49, J50, J56, J57,
J58, J59, J65, J88, J93,
J94, J95, 101, J102, J105,
J106, J107, J108, J110,
J119, J120, J121, J126,
J127, J128, J129, J130,
J131, J135, J138, J139,
J140, J141, J150, J151,
J152, J154, J155, J159,
J160, J161, J162, J163,
J172, J174, J175, J176,
J183, J184, J186, J187,
J197, J198, J199, J200,
J205
21-06000-00 L=5mm
J9, J10, J11, J13, J25, J26,
J32, J35, J36, J37, J39,
J40, J41, J44, J45, J47,
J48, J53, J62, J63, J64,
J67, J73, J99, J100, J104,
J117, J125, J143, J146,
J147, J164, J165, J166,
J168, J169, J170, J173,
J185, J192, J202, J203,
J204, J207
21-06000-00 L=7.5mm
J4, J43, J51, J52, J66, J87,
J89, J90, J91, J96, J111,
J113, J118, J122, J171,
J179, J180, J190, J201
21-06000-00 L=10mm
J12, J27, J61, J68, J69,
J72, J116, J123, J124,
J133, J134, J136, J137,
J142, J145, J149, J156,
J157, J158, J178, J191
21-06000-00 L=12.5mm
J30, J31, J54, J55, J80,
J132, J181, J182, J188,
J189, J193
21-06000-00 L=15mm
J8, J14, J15, J16, J17, J18,
J19, J20, J21, J33, J34,
J60, J76, J82, J112, J206
21-06000-00 L=18mm
J22, J23, J24, J75, J81,
J83, J92, J97, J98, J103,
J109, J144, J153, J195,
J196
21-06000-00 L=20mm
J74, J114, J115 21-06000-00 L=22.5mm
J70, J71, J77, J78, J84,
J85, J86, J177
21-06000-00 L=25mm
J2, J5 21-10750-00 L=7.5 (thick links)
J79 21-10101-00 L=10 (thick links)
J167 21-10201-00 L=20 (thick links)
J1, J6, J148 21-10251-00 L=25 (thick links)
CIRCUIT NO. PART NO. DESCRIPTIONS
TRANSISTORS
Q61, Q62 31-00170-00 2SK170
Q63, Q65 31-00970-00 2SA970
Q64, Q66 31-00647-00 2SB647A
Q67, Q68 31-00667-00 2SD667A
DIODES
D61, D62, D63, D64 33-44148-00 1N4148
CAPACITORS
C63, C64, 05-22012-01 22p, 100V, ±10%
C611(IN MODULE) 05-43012-01 43p, 100V, ±10%
C611(OUT MODULE) 05-75012-00 75p, 100V, ±10%
C69, C610 05-10151-00 100p, 50V, ±10%
C61, C62 05-22151-00 220p, 50V, ±20%
PCB-6:OUT MODULE ; PCB-7: IN MODULE
29
Line Out: 01-32560-02 and Line In: 01-32560-01
