C65, C66, C67, C68 24-10461-00 0.1uF, 63V, ±20%
RESISTORS
R617, R618, R619, R620 07-20100-50
10¡, 1/6W, ±5%
R615, R616 07-20330-50
33¡, 1/6W, ±5%
R61, R62 07-20221-50
220¡, 1/6W, ±5%
R69, R610 07-24300-50
430¡, 1/6W, ±1%
R67, R68, R611, R612 07-20102-50
1
K¡, 1/6W, ±5%
R613, R614 07-20103-50
10K¡, 1/6W, ±5%
R621 07-20303-51
30K¡, 1/4W, ±5%
R63, R64 07-20105-50
1M¡, 1/6W, ±5%
CONNECTER
S006 13-12509-01 CZ61
J61 21-06000-00 L=5
CIRCUIT NO. PART NO. DESCRIPTION
TRANSISTORS
Q26 31-01015-01 2SA1015
Q27 31-01815-01 2SC1815
Q22, Q25, R202, Q204 31-01312-00 2SA1312-GR
Q23, Q24, Q201, Q203 31-03324-00 2SC3324-GR
Q28 31-00647-00 2SB647A
Q29 31-00667-00 2SD667A
DIODES
D23, D24, D25, D26 33-44148-11 LL4148
RESISTORS
R254, R255 07-90100-01
10¡, ±5%
R215, R216 07-91509-01
15¡, ±1%
R249 07-96809-01
68¡, ±1%
R203, R206, R219, R220 07-98209-01
82¡, ±1%
R211, R212, R259 07-91000-01
100¡, ±1%
R269 07-93300-01
330¡, ±1%
R29, R201, R205, R210 07-93902-01
39K¡, ±1%
R223 07-94702-01
47K¡, ±1%
R221, R222 07-91003-01
100K¡, ±1%
R202, R204 07-92203-01
220K¡, ±1%
CAPACITORS
C28, C29 26-39051-01 39pF, 50V, ±5%
C22, C224 26-10251-11 1nF, 50V, ±5%
C23, C24 06-10031-02 VSS, 10uF, 35V, ±20%
C203, C204 06-22011-05 VSS, 22uF, 16V, ±20%
INDUCTORS
L22 08-04101-00 100uH
CONNECTER
S006 13-12508-11 CZ21
CIRCUIT NO. PART NO. DESCRIPTION
TRANSISTORS
Q16 31-01015-01 2SA1015
Q17 31-01815-01 2SC1815
Q12, Q15, Q102, Q104 31-01312-00 2SA1312-GR
Q13, Q14, Q101, Q103 31-03324-00 2SC3324-GR
Q18 31-00647-00 2SB647A
Q19 31-00667-00 2SD667A
DIODES
D13, D14, D15, D16 33-44148-11 LL4148
RESISTORS
R154, R155 07-90100-01
10¡, ±5%
R115, R116 07-91509-01
15¡, ±1%
R149 07-96809-01
68¡, ±1%
R103, R106, R119, R120 07-98209-01
82¡, ±1%
R111, R112, R159 07-91000-01
100¡, ±1%
PCB-4: AMP MODULE L SMD
PCB-5: AMP MODULE R SMD
01-32520-02
30
01-32520-01
