NAD C 325BEE - Page 31

R169 07-93300-01
330¡, ±1%
R19, R101, R105, R110 07-93902-01
39K¡, ±1%
R123 07-94702-01
47K¡, ±1%
R121, R122 07-91003-01
100K¡, ±1%
R102, R104 07-92203-01
220K¡, ±1%
CAPACITORS
C18, C19 26-39051-01 39pF, 50V, ±5%
C12, C124 26-10251-11 1nF, 50V, ±5%
C13, C14 06-10031-02 VSS, 10uF, 35V, ±20%
C103, C104 06-22011-05 VSS, 22uF, 16V, ±20%
INDUCTORS
L12 08-04101-00 100uH
CONNECTER
CZ11 13-12508-11 S006
CIRCUIT NO. PART NO. DESCRIPTION
DIODES
D717 33-50525-00
5 DUAL COLOR
SWITCHS
S78 11-04101-10
DTSG˄P˅-24N
CONNECTER
CB73———CZ73 14-32505-10
26AWG UL2468# white, 70mm
length
CIRCUIT NO. PART NO. DESCRIPTION
TRANSISTORS
Q59, Q510, Q517, Q519 31-01015-00 2SA1015 GR
Q518, Q520 31-01815-00 2SC1815 GR
DIODES
D513 33-24004-02 1N4004
33-24004-00 1N4004
D56 33-30142-00 DB104
D51, D55 33-30822-00 8A/200V
D531, D532 33-60116-00 TIC116D/BT151-500R
CAPACITORS
C54 25-47422-00
MKP62, 275V, 0.47uF 10%
MPX 275VAC 0.47uF 10%
C53 05-47242-00 4n7p, 400V, ±20%
78-001001-0 811810-23
C51, C52 25-10322-00 10n/250V 10%
C524 06-22251-00 2200u/50V 20%
C523 06-33251-00 3300u/50V 20%
C517, C518 06-15351-01 15000u/50V 10%, two foods
C517, C518 06-15351-02 15000u/50V 10%, two fods
RESISTORS
R561, R565 07-10101-51
100¡, ±5%, 1/4W
R532 07-10221-51
220¡, ±5%, 1/4W
R558, R559, R560, R562 07-10102-51
1
K
¡, ±5%, 1/4W
R534 07-10222-51
2.2K¡, ±5%, 1/4W
R566 07-10472-51
4.7K¡, ±5%, 1/4W
R544, R563, R564 07-10223-51
22K¡, ±5%, 1/4W
R567 07-10334-51
330K¡, ±5%, 1/4W
R533 07-10105-51
1M¡, ±5%, 1/4W
R531 07-40507-03
0.05¡, 3W, ±5%
FUSES
F51, F52, F53, F54 20-12632-00 T6.3AL250V
F55 20-12501-00 T500mAL/250V
F51, F52, F53, F54 20-20000-00 HF-004
CONNECTERS
CB52, CB54, CB58 13-23902-00 VH 3.96A-2A
CB55, CB56, CB59 13-23903-01
VH 3.96A-3A(delete the center
needle)
CB57 13-23903-11
VH 3.96A-3A(delete the center
needle)
CB51 13-23907-10 VH 3.96A-7A
PCB-8: STANDBY BOARD
PCB-2: POWER BOARD
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
31
