CB53——CB47 14-32507-10
SCN 2.5A-7D needles,XHB 2.5A-7Y
plug. 26AWG UL2468# white,
230mm length
LINKS
J52, J57, J513, J517 21-06000-00 L=5
J516, J520 21-06000-00 L=7.5
J51 21-06000-00 L=10
J514 21-10101-00 L=10
J54, J58, J518 21-06000-00 L=12.5
J510 21-06000-00 L=15
J56 21-10151-00 L=15
J515 21-06000-00 L=18
J519 21-10201-00 L=20
J512 21-06000-00 L=25
CIRCUIT NO. PARTS NO DESCRIPTION
ICS
IC71 03-02402-00 24C01A/24C02(A)/24C04(A)
IC74, IC75 03-04094-00 CD4094/HEF4094
IC73 03-04051-22 AT89C4051-12PU
IC73 03-04051-12 AT89C4051-12PU
IC76 03-00810-02 TCM810MENB
TRANSISTORS
Q72, Q73, Q74, Q79, Q710,
Q711, Q712, Q713, Q714,
Q715, Q716, Q717, Q718
31-01815-00 2SC1815
DIODES
D710, D711, D712, D713,
D714, D715
33-44148-00 1N4148
D718 33-44148-00 1N4148
D71 ,D72, D73, D74, D76,
D77, D716
33-50350-00
¶3 GREEN LED
D75 33-50340-00
¶3 AMBER LED
CRYSTAL
Y71 04-11102-00 11.0592MHz, CL=15pF
CAPACITORS
C79, C710 05-27051-00 27p, 50V, ±10%
C724, C725 N.I.
C77, C714, C715, C716,
C717, C718, C719, C720,
C721
24-10312-00 10nF, 100V, ±20%
C72, C78, C711, C712 24-10461-00 100nF, 63V, ±20%
C722 N.I.
C71, C723 06-10111-00 100uF, 16V, ±20%
RESISTORS
R71 07-10331-50
330¡, 1/6W, ±5%
R72 07-10471-50
470¡, 1/6W, ±5%
R701, R703, R725, R759 07-10222-50
2K2¡, 1/6W, ±5%
R726, R727 07-10222-51
2K2¡, 1/4W, ±5%
R748, R749, R750, R751,
R752, R754, R760, R766
07-10472-50
4K7¡, 1/6W, ±5%
R741, R742, R743, R744,
R745, R746, R747, R753,
R761
07-10472-51
4K7¡, 1/4W, ±5%
R733 07-10512-51
5K1¡, 1/4W, ±5%
R702, R73, R756, R757,
R758, R762, R763, R764
07-10103-50
10K¡, 1/6W, ±5%
R708 07-10103-51
10K¡, 1/4W, ±5%
R730 07-10153-50
15K¡, 1/6W, ±5%
SWITCHS
S71, S72, S73, S74, S75,
S76, S77
11-04101-00 IT-1102D-1160
CONNECTERS
PCB-3: KEY BOARD
32
