NAD C 325BEE - Page 33

CZ71--CB34 14-32509-00
SCN 2.5A-9D needle,XHB 2.5A-9Y
plug. 26AWG UL2468#, white ,
400mm length
CZ72--CB31 14-32510-00
SCN 2.5A-10D needle,XHB 2.5A-
10Y plug. 26AWG UL2468#, white ,
430mm length
LINKS
J71, J72, J73, J74, J75,
J79, J710, J716, J733,
J735, J745, J746, J747,
J749, J753, J794
21-06000-00 L=5
J76, J77, J78, J715, J717,
J718, J727, J738, J740,
J742, J744, J752, J793
21-06000-00 L=7.5
J713, J720, J729, J734,
J737, J743, J750
21-06000-00 L=10
J711, J719, J726, J728,
J730, J731, J732, J776,
J792
21-06000-00 L=12.5
J712, J724, J739 21-06000-00 L=15
J714, J748 21-06000-00 L=18
J721, J722, J723, J725,
J736, J741
21-06000-00 L=20
CIRCUIT NO. PART NO. DESCRIPTION
DIODES
D719 33-50350-00
¶3 GREEN LED
CAPACITORS
C758, C759 05-10151-01 100p, 50V, ±10%
C760 24-10461-00 0.1uF, 63V, ±20%
RESISTORS
R766 07-10100-50
10¡, 1/6W, ±5%
CONNECTER
PHONE71 17-02001-02 SCJ340R0GBS0B00
TP701--front panel 14-32501-12
1007#
,
24AWG
,
black
,
35mm
length
CZ75——CB35 14-32503-11
SCN 2.5A-3D needles,XHB 2.5A-3Y
plugDŽUL1691, 24AWG/26AWG,
white/red/black, 675mm length.
CB74——CZ74 14-32504-10
SCN 2.5A-4D needles. 26AWG
UL2468# ,red/white, 70mm length.
CIRCUIT NO. PART NO. DESCRIPTION
RESISTORS
R454, R455 07-30101-04
100¡ 2W ±5%
CONNECTER
CZ45--CB45 14-32505-01
XHB 2.5A-5Y plug,26AWG
UL2468# white, 410mm length
CZ45 13-22505-00 XHB2.5A-5A
LINKS
J41 21-06000-00 L=5mm
CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC72 03-00038-40 HS0038B4
CONNECTER
CZ72--CB72 14-32503-10
SCN 2.5A-3D needles˗26AWG
UL2468# ,red/whiteˈ60mm len
g
th
CIRCUIT NO. PART NO. DESCRIPTION
TRANSFORMER
C VERSION 18-32515-20 TD-230-0150G
AH VERSION 18-32515-10 TD-120-0150G
METAL PARTS
Busbar 69-065001-0 T2Y2 T=1mm
Heatsink (SMALL1) 70-065001-0 ALU 6063 BLACK
PCB-9: IPOD BOARD
PCB-10: HEADPHONE BOARD
PCB-11: IR BOARD
OTHERS
Ƹ
!
Ƹ
!
33
