NAD C 325BEE - Page 34

Heatsink (SMALL2) 70-065002-0 ALU 6063 BLACK
Machine Screw 61-022510-5 MB2.5×10
Machine Screw 61-022514-5 MB2.5×14
Nut 62-010202-5 M2.5
RIVET 61-382003-5 GB975-86-2.5×3
CONNECTERS
14-32502-23
VH 3.96A-3Y(delete
center needle) plug.
18AWG UL1672#,
red/blue,180mm
length.
CB59——AC OUTLET(AH)
14-32502-33
VH3.96A-3Y(delete
center needle)
plug,18AWG
UL1672# .
red/blue,160mm
length.
CB56——POWER SWTICH
15-02251-20 WB01HS-001
AC CORD˄C˅
15-10121-10 WB05HS-001
AC CORD˄AH˅
15-02251-30 2GTJ1
AC CORD˄CCC˅
17-07002-10 JY0647A AC Outlets(AH)
11-01101-03
RF-1003-BB2, 10A
250V, TV-5
SW52
NOTES: AH C
TRANSFORMER
TD-120-0150L TD-230-0150C
AC CORE
WB05HS-001 WB01HS-001
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
Ƹ
!
34
