AUDIO SPECIFICATIONS
ANALOG IN/HEADPHONE OUT
THD (20 Hz – 20 kHz) <0.005 % at 1 V out
Signal-to-Noise Ratio >100 dB (A-weighted, 32 ohms, ref. 2V
out, unity gain)
Frequency response ±0.3 dB (20 Hz - 20 kHz)
Output impedance 11 ohms
ANALOG IN/SUBWOOFER OUT
THD (20 Hz – 20 kHz) <0.005 % at 1 V out
Signal-to-Noise Ratio >100 dB (A-weighted, 32 ohms, ref. 2V
out, unity gain)
Frequency response ±0.2 dB (20 Hz - 20 kHz)
Gain 17 dB
Output impedance 200 ohms
ANALOG IN/SPEAKER OUT
Continuous output power into 8 ohms
and 4 ohms
40W (ref. 20 Hz-20 kHz at rated THD, both
channels driven)
THD (20 Hz – 20 kHz) <0.03 % (100 mW to 40 W, 8 ohms and
4 ohms)
Signal-to-Noise Ratio >95 dB (A-weighted, 500 mV input, ref.
1W out 8 ohms)
Gain 37 dB
Clipping power >50 W (at 1 kHz 0.1 % THD)
IHF dynamic power 8 ohms: 90 W
4 ohms: 166 W
Peak output current >18A (in 1 ohm, 1 ms)
Damping factor >100 (20 Hz - 20 kHz)
Frequency response ±0.3 dB (20 Hz - 20 kHz)
Channel separation >85 dB (1 kHz)
>70 dB (10 kHz)
Input sensitivity (for 40 W in 8 ohms) 250 mV
Standby power <0.5 W
PHONO IN/SPEAKER OUT
THD (20 Hz – 20 kHz) <0.03 % (200 mW to 40 W, 8 ohms and
4 ohms)
Signal-to-Noise Ratio >75 dB with IHF MM cartridge
(A-weighted, ref. 5mV input, 1 kHz and
1W output in 8 ohms)
Frequency response (RIAA deviation) ±0.3 dB (20 Hz - 20 kHz)
Note: The RIAA response is consistent with
a pre-emphasis that is rolled o at 50kHz
by a second order lter, such as used in
Neumann cutting lathes.
Channel separation >80 dB (1 kHz, 8 ohms, 50 mV input,
13W out)
>60 dB (10 kHz, 8 ohms, 50 mV input,
13W out)
Input sensitivity (for 40 W in 8 ohms) 3.6 mV
DIGITAL IN/SPEAKER OUT
THD (20 Hz – 20 kHz) <0.03 % (100 mW to 40 W, 8 ohms and
4 ohms)
Signal-to-Noise Ratio >95 dB (A-weighted, -12 dBFS input, ref.
1W out in 8 ohms)
Frequency response ±0.3 dB (20 Hz - 20 kHz)
Gain 47 dB (Vrms/FS)
Channel separation >80 dB (1 kHz)
>70 dB (10 kHz)
DIMENSION AND WEIGHT
Gross dimensions (W x H x D) 435 x 70 x 285 mm
17 ⁄ x 2 ⁄ x 11 ¼ inches
Net weight 4.9 kg (10.8 lbs)
Shipping weight 5.9 kg (13.0 lbs)
* - Gross dimension includes feet, volume knob and extended rear panel terminals.
Specifications are subject to change without notice. For updated documentation and features, please
check out www.NADelectronics.com for the latest information about C 328.
REFERENCE
SPECIFICATIONS
All specs are measured according to IHF 202 CEA 490-AR-2008 standard. THD is measured using AP AUX 0025 passive lter and AES 17 active lter.
