IR CHANNEL
IR Channel
}~CH0
`CH1
`CH2
The C 390DD has the capability to operate over four IR channel settings.
This is practically useful if you have several NAD products that can be
operated by similar remote control commands. With varying IR Channel
settings, dierent NAD products can be controlled independently in the
same zone by setting each one to a dierent IR channel.
IR CHANNEL ASSIGNMENT
The C 390DD and the AVR 4 remote control must be set to the same
channel.
To change the IR Channel on the C 390DD
• While at “IR Channel” menu, use the [D/F] to select through CH 0
to CH 3. Press [S] to select preferred IR Channel setting. C 390DD IR
Channel is defaulted to CH0.
To change the IR Channel on the AVR 4 remote control
• Include a channel number before the library code. For AVR 4, library
code “10” is the default library table for “AMP” device. To select this “AMP”
library table for IR Channel 0 (CH0), retain the library code “10” (or “010”).
• If you want to load the “AMP” library table on ”IR Channel 1” (CH1) prex
the library code with “1” to indicate association with “IR Channel 1” (CH1).
Load then the “AMP” library table using the code “110”. Repeat the same
for MP (130) and TUNER (140).
SAMPLE SETUP OF TWO NAD PRODUCTS ON THE SAME ZONE
NAD C 390DD and NAD C 326BEE are both defaulted to IR Channel 0. If
[OFF] button is pressed on the AVR 4 remote control (or SR 8 remote control
for the C 326BEE), both products will go to standby mode. Press [ON] and
both products will power up from standby mode.
To prevent both products from simultaneously going in and out of standby
mode along with other common commands, set each one to a dierent
IR channel. In this setup, we will keep C 326BEE and SR 8 remote control
defaulted to “IR Channel 0” (CH0). As for C 390DD, we will assign it to
“IRChannel 1” (CH1); the same applies to AVR 4.
Set C 390DD and AVR 4 to “CH1” via the following procedure.
C 390DD
• While at “IR Channel” menu, use the [D/F] to go to “CH1” setting. Press
[S] or [ENTER] to select “CH1”. Press [A] to exit IR Channel selection.
AVR 4
• Press and hold [AMP] in the DEVICE SELECTOR section of the AVR 4.
• While holding down the device button [AMP], press “1”, “1” and “0” using
AVR 4’s numeric buttons.
• Press [ENTER] while still holding down the device button [AMP]. The
AMP device selector will ash once to indicate that the library input is
successful.
With both C 390DD and AVR 4 set to “CH1”, the C 326BEE can now be
remotely controlled independent of the C 390DD.
NOTE
Performing a Factory Reset for C 390DD or AVR 4 will result to a return to
the factory default “IR Channel 0” setting.
SOURCE SETUP
Source Setup
}Digital Coaxial 1
Digital Coaxial 2
Digital Optical 1
Source Setup makes it possible to select a Source and enable or disable it as
desired. The optional NAD DD AP-1 (Direct Digital Analog Phono) module
must be installed for “Single-ended” and “Balanced” sources to be functional.
The same applies for “Digital HDMI 1”, “Digital HDMI 2” and “Digital HDMI 3” -
the optional NAD DD HDMI-1 (HDMI) module must also be installed. If the
applicable module is not installed, the corresponding sources will not be
available from the Source Setup menu selection.
SINGLE-ENDED/BALANCED
Single-ended
}~Enable
`Disable
Balanced
}~Enable
`Disable
There are two options when Single-ended or Balanced input is enabled -
Level Trim and Sample Rate.
NOTE
The optional NAD DD AP-1 (Direct Digital Analog Phono) module must
be installed for “Single-ended” and “Balanced” sources to be functional.
Otherwise, aforementioned sources will not be available from the
Source Setup menu selection.
OPERATION
USING THE C 390DD
18
