NAD C 545BEE - Electrical Parts List; Resistors (Part 3)

- 39 -
Location Part Number Description
R299 4723-331A+P RMG 1/16W 330R 1% 0603
R3 4723-472A+P RMG 1/16W 4.7K 1%.
R300 4723-103A+P-R RMG 1/16W 10K 1% 0603
R302 4711-220A+2 RMF 1/8W 22R 1% AT
R303, R304, R305 4723-472A+P RMG 1/16W 4.7K 1%.
R306 4711-472A+2 RMF 1/8W 4.7K 1% AT
R307 4723-101A+P RMG 1/16W 100R 1% 0603
R308 4723-104A+P-R RMG 1/16W 100K 1% 0603
R310, R311 4723-472A+P RMG 1/16W 4.7K 1%.
R314, R315, R316, R317 4723-220A+P RMG 1/16W 22R 1% 0603
R318 4723-103A+P-R RMG 1/16W 10K 1% 0603
R319 4723-104A+P-R RMG 1/16W 100K 1% 0603
R321 4723-103A+P-R RMG 1/16W 10K 1% 0603
R322, R323 4723-562A+P RMG 1/16W 5.6K 1%
R324, R325 4723-752A+P RMG 1/16W 7.5K 1%
R328, R329 4723-562A+P RMG 1/16W 5.6K 1%
R330, R331 4723-752A+P RMG 1/16W 7.5K 1%
R334, R335 4711-472A+2 RMF 1/8W 4.7K 1% AT
R336, R337 4723-242A+P RMG 1/16W 2.4K 1% 0603
R338 4723-103A+P-R RMG 1/16W 10K 1% 0603
R339 4723-622A+P RMG 1/16W 6.2K 1%
R340 4723-470A+P RMG 1/16W 47R 1% 0603
R341 4723-622A+P RMG 1/16W 6.2K 1%
R342 4723-470A+P RMG 1/16W 47R 1% 0603
R343 4723-103A+P-R RMG 1/16W 10K 1% 0603
R346, R347 4723-470A+P RMG 1/16W 47R 1% 0603
R348, R349 4723-101A+P RMG 1/16W 100R 1% 0603
R350, R351, R352, R353 4723-472A+P RMG 1/16W 4.7K 1%.
R354 4723-331A+P RMG 1/16W 330R 1% 0603
R355 4723-102A+P RMG 1/16W 1K 1%
R356 4723-472A+P RMG 1/16W 4.7K 1%.
R357 4720-100A+J RMG 1/10W 10R 1% 0805
R4 4723-103A+P-R RMG 1/16W 10K 1% 0603
R452 4711-103A+2 RMF 1/8W 10K 1% AT
R5 4723-222A+P RMG 1/16W 2.2K 1%
R6 4723-472A+P RMG 1/16W 4.7K 1%.
R7 4723-222A+P RMG 1/16W 2.2K 1%
IC
IC202 3130-2020+2 IC NJM7805FA-#ZZZB
IC203 3130-2520+2 IC NJM7812FA-#ZZZB
IC204, IC208 3132-2821+0 IC LM1117S-3.3
IC206 3132-6791+0-20 IC MCU TMP86FS49AUG
IC207 3132-6730+0 IC MEMORY 24C1024 SOIC8
