NAD C 545BEE - Component Lists; Integrated Circuits (ICs)

- 40 -
Location Part Number Description
IC209 3132-6740+0 IC REGULATOR TA48015F
U1 3131-3970+0 IC DS1233DZ-5+T&R
U2 3130-2020+2 IC NJM7805FA-#ZZZB
U201 3131-9100+0 IC SN74HCU04D (SOP)
U202 3131-7990+0 IC TA7291SG(5/M)22240239
U203 3131-5160+0 IC DUAL VOLTAGE
U204 3130-3800+0 IC NJM7912FA-#ZZZB
U206, U207 3130-2020+2 IC NJM7805FA-#ZZZB
U208 3132-4401+0 IC REG LM1086IT-ADJ
U209 3131-9940+0 IC D/A CONVERTER WM8740E
U210, U211 3131-7620+0 IC OPA2134PA DIP OP AMP
U3 3131-9330+0 IC QUAD 2INPUT EXCLUSIVE
TRANSFORMER
T201 1806-4048+0007 TRANSFORMER PWR IN 115/
HEATSINK
H201 5400-1702+0 HEATSINK 23.5X17X50
H202, H203, H204, H205, H206 5400-9130+0 HEAT SINK FOR 7805 2438-
H207 5400-1702+0 HEATSINK 23.5X17X50
SCREW
Screw001 2954-3008+0000 SCREW B-TITE BIND M3X8
Screw002 2954-2606+0000 SCREWS BT 2.6X6
MISCELLANEOUS
AC201 7013-0710+0 WIRE-CONN 1P #20 UL1672
CON201 2101-3237+0 CONNECTOR FFC 18P P1.25
D201 4811-111A+3 LIGHT TX JST1111A
FC201, FC202, FC203, FC204, FC205 4131-9131+0 FUSE HOLDER 6.5MM PITCH
HT 2601-2604+0471 FIBRE WASHER M2.6X0.4X4.
IC206 3000-9812+0 BLANK LABEL (5X10)
IC206-A 312A-0410+01 SOFTWARE MCU V0.3.6 D
J210 2101-3233+0 WAFER SOCKET 11P P3.96
J216 2113-3320+0 JACK MONO 1P RED
J219 2101-3256+0 CONNECTOR FFC 6P P1.0
L204, L205 1808-0887+0 FERRITE BEAD 1.25X2 0805
P202, P203, P204, P205 4132-1061+0 SOLDER TAG
P218 2113-3328+0 PLUG DC 1P 100V 2A
RCA201 2113-2021+2 JACK RCA 1P ORANGE
