- 41 -
Location Part Number Description
SWITCH ASSY
D/E SVC-C54516+SW PCB ASSY SWITCH part of fascia
PC BOARD
I 1725-971A+0002/A PCB MAIN/KEY/SWITCH S/S
TRANSISTOR
Q101 4860-0640+3 TR 3904 HFE 100-300 SM
RESISTOR
R101 4720-472A+J RMG 1/10W 4.7K 1% 0805
R102 4720-122A+J RMG 1/10W 1.2K 1% 0805
R116 4720-471A+J RMG 1/10W 470R 1% 0805
SWITCH
S106 5200-4905+0 Replaces 5200-4861+0-01 TACT
LED
D101 3700-2846+B LED SP 2.9X5.4XL0.5 BLUE
D102 3700-2823+C LED LOW CURRENT SP
MISCELLANEOUS
CN102A 7013-0530+0 WIRE-CONN 4P P2.0 #28
SERVO ASSY
A SVC-
C54516+SERVO
PCB ASSY SERVO
PC BOARD
E 1725-970A+0001 PCB SERVO BOARD D/S FR-4
CAPACITOR
C1, C10, C11, C12, C13, C14, C15, C16, C17, C18, C19,
C2, C20, C21, C22, C23, C24, C25, C26, C27, C28,
C29, C3
150F-104K+P-AC CC 50V 0.1uF 10%
C30, C31 157D-226M+K-IU CE 16V 22U 20% RLT 5x11
C32, C33, C34 157D-107M+K-LUTU CE 16V 100U 20% RLT
C35 15CH-470J+P-AC CTC 0/60 47PF 5% 0603
C36, C37, C38 150F-333J+P-AC CC 50V 0.033UF 5% 0603
C39 157D-107M+K-LUTU CE 16V 100U 20% RLT
C4 150F-104K+P-AC CC 50V 0.1uF 10%
C40, C41, C42 150F-103J+P-AC CC 50V 0.01U 5% 0603
C43, C44 150F-153J+P-AC CC 50V 0.015U 5% 0603
C45 15CH-680J+P-AC CTC 0/60 68PF 5% 0603
