NAD C 545BEE - Component Lists; Transistors (Part 3); Resistors (Part 4)

- 43 -
JP8 2102-040S+003 WAFER 4P P2.0 STRAIGHT
SW1 2101-0661+0 SHUNT 2P P=2.54
SW1 2101-1495+0 WAFER 3PIN P=2.54 ST 6MM
JACK/SOCKET
J4 2113-1837+0 NPLG-6P-134 25055150
CRYSTAL
X1 2300-0110+0 CRYSTAL 16.9344 MHZ
X5 2300-3306+0 CRYSTAL QUARTZ 32.768KHZ
X6 2300-3317+0 CRYSTAL 9.0MHZ +/-30PPM
TRANSISTOR
Q1 4858-56B0+3 TR BC856B SOT23 PHILIPS
Q2 4851-4570+5 TR PNP 2SB1457 TO-92 RL
Q3, Q4, Q6 4860-0700+K TR 2SC1815-GR(TE2/F/T) R
Q7 4852-668Y+U TR NPN 2SC2668 Y:100-200
RESISTOR
R1 4723-100J+P-R RMG 1/16W 10R 5% 0603
R12, R13, R14, R16, R17, R19, R20, R22, R27, R36,
R39, R41, R42, R45, R47, R48, R49, R52, R57, R58,
R59, R61, R66, R67, R69, R78, R79, R8, R80, R81,
R82, R83, R84, R85, R86, R87, R88, R89, R90, R91,
R92, R93, R94, R95
4723-103A+P-R RMG 1/16W 10K 1% 0603
R10, R37, R38 4723-104A+P-R RMG 1/16W 100K 1% 0603
R15 4723-223A+P-R RMG 1/16W 22K 1% 0603
R73 4723-471A+P-R RMG 1/16W 470R 1% 0603
R100, R101, R102, R103, R46, R5, R96, R97, R98, R99 4723-473A+P-R RMG 1/16W 47K 1% 0603
R18 4723-560J+P-R RMG 1/16W 56R 5% 0603
JP1, JP15 4723-000J+P-R RMG 1/16W 0R 5% 0603
JP2 4723-332A+P-R RMG 1/16W 3.3K 1% 0603
JP3, JP4 4723-000J+P-R RMG 1/16W 0R 5% 0603
JP5 4723-472A+P RMG 1/16W 4.7K 1%.
JP6 4723-133A+P-R RMG 1/16W 13K 1% 0603
R11 4723-472A+P RMG 1/16W 4.7K 1%.
R2 4723-154A+P-R RMG 1/16W 150K 1% 0603
R21 4723-101A+P RMG 1/16W 100R 1% 0603
R24 4723-000J+P-R RMG 1/16W 0R 5% 0603
R25, R26 4723-270A+P RMG 1/16W 27R 1% 0603
R29 4723-221A+P RMG 1/16W 220R 1%
R3 4723-153A+P RMG 1/16W 15K 1%
R30, R31, R32 4723-105A+P RMG 1/16W 1M 1% 0603
R33, R34 4723-153A+P RMG 1/16W 15K 1%
R35 4723-331A+P RMG 1/16W 330R 1% 0603
Location Part Number Description
