- 44 -
R4 4723-334J+P RMG 1/16W 330K 5%
R40 4723-101A+P RMG 1/16W 100R 1% 0603
R43, R44 4723-000J+P-R RMG 1/16W 0R 5% 0603
R54 4723-000J+P-R RMG 1/16W 0R 5% 0603
R55, R56 4723-101A+P RMG 1/16W 100R 1% 0603
R6 4723-472A+P RMG 1/16W 4.7K 1%.
R60 4723-220A+P RMG 1/16W 22R 1% 0603
R62 4723-220A+P RMG 1/16W 22R 1% 0603
R63 4723-472A+P RMG 1/16W 4.7K 1%.
R64 4723-220A+P RMG 1/16W 22R 1% 0603
R65 4723-391A+P RMG 1/16W 390R 1%
R68 4723-152A+P-R RMG 1/16W 1.5K 1% 0603
R7 4723-910A+P RMG 1/16W 91R 1% 0603
R70 4723-102A+P RMG 1/16W 1K 1%
R71 4723-103A+P-R RMG 1/16W 10K 1% 0603
R72 4723-153A+P RMG 1/16W 15K 1%
R75, R76, R77 4723-220A+P RMG 1/16W 22R 1% 0603
R9 4723-562A+P RMG 1/16W 5.6K 1%
IC
IC1 3132-6711+0-20 IC DSP TC94A73MFG
IC10 3132-6761+0 IC MEMORY EPROM
IC3 3132-6740+0 IC REGULATOR TA48015F
IC5 3132-7331+0 IC MCU TMP92FD28A
IC77 3132-2821+0 IC LM1117S-3.3
IC8 3132-6720+0 IC REGULATOR TA4805F SMD
U2 3132-3231+0 IC MOTOR DRV W/3.3V REG
MISCELLANEOUS
IC5 3000-9812+0 BLANK LABEL (5X10)
IC5-A 312A-0520+01 SOFTWARE SERVO MCU V4.0 D
J3 2101-3102+0 CONNECTOR FFC 16PIN P1.0
L1 1803-0055+0 INDUCTOR CHIP 10UH
X6 2300-3317+0 CRYSTAL 9.0MHZ +/-30PPM
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
- Capacitors : CP-Polystyrene, CM-Mylar, CE-Electrolytic, CC-Ceramic, CTC-NPO.
- Resistors : RMF-Metal Film, RCF-Carbon Film, RWR-Wirewound Metal Oxide.
Location Part Number Description
