NAD C 565BEE - Page 43

- 43 -
Location Part Number Description
D221 481X-147L+2 PHOTO RECEIVER TORX147L
D222 481T-X147+2 PHOTO TRANSMITTER
F200, F201, F202, F203, F204, F205, F206, F207, F208,
F209
4131-9131+0 FUSE HOLDER 6.5MM PITCH
HS200 5400-9132+0 HEATSINK 7805 2438-17
IC206 3000-9812+0 BLANK LABEL (5X10)
IC206-A 312A-0580+01 SOFTWARE MCU V1.3.3 D
J201 2101-3233+0 WAFER SOCKET 11P P3.96
J202 2113-1749+0 SOCKET DB9 D SUB RA
J205 2113-2036+1 JACK PHONE 4P RED D315
J206 *AH 635N-0002+0 WJ ROLLER FORM D=0.6MM
J207 *C 635N-0002+0 WJ ROLLER FORM D=0.6MM
L201, L202 1808-0887+0 FERRITE BEAD 1.25X2 0805
L205, L206 1803-0055+0 INDUCTOR CHIP 10UH
L208, L209, L210, L212, L213, L214 1808-0887+0 FERRITE BEAD 1.25X2 0805
P221 7012-9720+1 WIRE-CONN 1P #22 UL1015
P222 7012-6965+0 CONN WIRE 1P GND UL1015
RCA200 2113-2021+2 JACK RCA 1P ORANGE
PWR ASSY
C SVC-C56516+PWR PCB ASSY PWR
PC BOARD
C 1725-982A+0001
PCB MAIN/VFD/USB/PWR/VOL D
CAPACITOR
C230 157T-475M+5-S5T CE 400V 4.7U 20% RL
C232 150T-222M+5-SK CC 400V 2200P 20% RL
C233 157D-477M+K-SXTU CE 16V 470U 20% RLT
C235 153H-102J+K-IQ CM 100V 0.001U 5% RLT 5X
C236 150F-104J+P-AC CC 50V 0.1U 5% 0603
C237 157T-475M+5-S5T CE 400V 4.7U 20% RL
C366 157F-106M+K-IU CE 50V 10U 20% RLT 5X11
C367 150F-104J+P-AC CC 50V 0.1U 5% 0603
Y200 150T-222M+5-SK CC 400V 2200P 20% RL
DIODE
D203 4840-8530+2 RECTIFIER UF4006-T GI AT
D204, D205, D206, D207 4804-0070+2 DIODE IN4007-F AT
D208 4804-0010+2 DIODE W1N4001-A(WA) AT
D209, D229 4801-48W0+3 DIODE 1N4148W SOD-123
