- 44 -
Location Part Number Description
WAFER/SOCKET
AC200 2101-1432+0 WAFER 2P P7.92 JAPAN
COIL
L203 1807-273J+PS COIL 27MH 5% 8.3X9.7
L207 1806-4041+0000 CHOKE COIL 7.7MH 10%
RELAY
RL200 4500-0762+0 RELAY 5VDC 10A SPDT
RL205 4500-0753+0 RELAY 5VDC 1A DPDT BP-5
TRANSISTOR
Q206, Q208 4858-46B0+3 TR BC846B SOT23 PHILIPS
RESISTOR
R256 4723-563A+P-R RMG 1/16W 56K 1% 0603
R227 4723-202A+P RMG 1/16W 2K 1%
R262, R266 4723-102A+P RMG 1/16W 1K 1%
R267 4718-104J+2 RMF 1W 100K 5% AT
R425 4723-102A+P RMG 1/16W 1K 1%
R466 4723-202A+P RMG 1/16W 2K 1%
TRANSFORMER
T200 1806-4052+0000
TRANSFORMER PWR 110-230V
FUSE
FC205
5120-1096+0 FUSE 0.8A 250V 8X7 UL
MISCELLANEOUS
AC203 7013-0920+0 WIRE-POWER 2P P7.92 #18
D230 3132-2981+0 IC ADJUST SHUNT REG
JP221 7013-0600+0 WIRE-SHILED 4P P2.0 #24
U201 3132-7351+0 IC POWER NCP1014 PDIP7
U215 481C-817A+3 PHOTOCOUPLER LTV817A
USB ASSY
F SVC-C56516+USB PCB ASSY USB
PC BOARD
F 1725-982A+0001 PCB MAIN/VFD/USB/PWR/VOL D
