NAD C 565BEE - Page 45

- 45 -
Location Part Number Description
CAPACITOR
C395 150F-103J+P-AC CC 50V 0.01U 5% 0603
JACK/SOCKET
JP107 2113-3205+0 SOCKET USB USB-A-S-01
MISCELLANEOUS
JP108 7013-0601+0 WIRE-SHILED 4P P2.0 #24
L222 1808-0887+0 FERRITE BEAD 1.25X2 0805
VFD ASSY
B SVC-C56516+VFD PCB ASSY VFD part of fascia
PC BOARD
B 1725-982A+0001
PCB MAIN/VFD/USB/PWR/VOL D
CAPACITOR
C141 150F-104J+P-AC CC 50V 0.1U 5% 0603
C142 157E-106M+K-IUK CE 25V 10U 20% RLT 5X11
C143 150F-104J+P-AC CC 50V 0.1U 5% 0603
C144 157F-105M+K-GM CE 50V 1U 20% RLT 4X7
C145 150F-104J+P-AC CC 50V 0.1U 5% 0603
C146, C147 15CH-470J+P-AC CTC 0/60 47PF 5% 0603
C150, C151, C152 150F-100J+P-AC CC 50V 10P 5% 0603
C153 150F-104J+P-AC CC 50V 0.1U 5% 0603
DIODE
D143 4801-48W0+3 DIODE 1N4148W SOD-123
Z101 4837-5B61+2 DZ 1/2W 5.45-5.73 ROHM
WAFER/SOCKET
JP110 2102-040R+J01 WAFER 4P P2.0 90DEG
TRANSISTOR
Q142 485C-1140+3 TR DTC114YKA 2216470R2
RESISTOR
R146 4723-332A+P-R RMG 1/16W 3.3K 1% 0603
R143, R144, R145 4723-471A+P-R RMG 1/16W 470R 1% 0603
R155 4723-473A+P-R RMG 1/16W 47K 1% 0603
R147 4723-751A+P RMG 1/16W 750R 1% 0603
