Location Part Number Description
R148 4723-222A+P RMG 1/16W 2.2K 1%
R149 4723-682A+P RMG 1/16W 6.8K 1%
R150 4723-303A+P RMG 1/16W 30K 1%
R151 4723-751A+P RMG 1/16W 750R 1% 0603
R152 4723-222A+P RMG 1/16W 2.2K 1%
R153 4723-682A+P RMG 1/16W 6.8K 1%
R154 4723-303A+P RMG 1/16W 30K 1%
R156, R157 4723-472A+P RMG 1/16W 4.7K 1%.
R158, R159 4723-220A+P RMG 1/16W 22R 1% 0603
R161, R162, R163 4723-330A+P RMG 1/16W 33R 1% 0603
R165 4723-102A+P RMG 1/16W 1K 1%
R166 4720-470A+P RMG 1/10W 47R 1% 0603
R167 4723-330A+P RMG 1/16W 33R 1% 0603
SWITCH
S101, S102, S103, S104, S105, S106, S107, S108 5200-4905+0 Replaces 5200-4861+0-01 TACT
MISCELLANEOUS
CON141B 7013-0530+0 WIRE-CONN 4P P2.0 #28
CON142 2101-3237+0 CONNECTOR FFC 18P P1.25
Cusion1 4154-4881+1 CUSHION 21X8X2
L141 1808-0887+0 FERRITE BEAD 1.25X2 0805
M1, M2 4135-8341+0 HOLDER-VFD TINNED STEEL
REM0101 4816-043T+3 IR SENSOR KSM-603TM2
REM101 4151-9671+1 SPONGE 12X10X3
VFD101 2460-2270+0 DISPLAY-VFD MODULE
VOL ASSY
D SVC-C56516+VOL PCB ASSY VOL part of fascia
PC BOARD
D 1725-982A+0001
PCB MAIN/VFD/USB/PWR/VOL D
CAPACITOR
C148, C149 150F-103J+P-AC CC 50V 0.01U 5% 0603
MISCELLANEOUS
JP109 7013-0490+0 WIRE-CONN 4P P2.0 #28
T100 5200-4978+0 ENCODER PUSH ROTARY
SPST
2460-2270+1 IMPROVED BRIGHTNESS VFD
