- 47 -
SERVO ASSY
G SVC-C56516+SERVO PCB ASSY SERVO
PC BOARD
E 1725-970A+0001 PCB SERVO BOARD D/S FR-4
CAPACITOR
C1, C10, C11, C12, C13, C14, C15, C16, C17, C18, C19,
C2, C20, C21, C22, C23, C24, C25, C26, C27, C28,
C29, C3
150F-104K+P-AC CC 50V 0.1uF 10%
C30, C31 157D-226M+K-IU CE 16V 22U 20% RLT 5x11
C32, C33, C34 157D-107M+K-LUTU CE 16V 100U 20% RLT
C35 15CH-470J+P-AC CTC 0/60 47PF 5% 0603
C36, C37, C38 150F-333J+P-AC CC 50V 0.033UF 5% 0603
C39 157D-107M+K-LUTU CE 16V 100U 20% RLT
C4 150F-104K+P-AC CC 50V 0.1uF 10%
C40, C41, C42 150F-103J+P-AC CC 50V 0.01U 5% 0603
C43, C44 150F-153J+P-AC CC 50V 0.015U 5% 0603
C45 15CH-680J+P-AC CTC 0/60 68PF 5% 0603
C46 150F-102J+P-AC CC 50V 1000P 5% 0603 X7R
C48 150F-750J+P-AC CC 50V 75P 5% 0603
C49 150F-560J+P-AC CC 50V 56P 5% 0603
C5 150F-104K+P-AC CC 50V 0.1uF 10%
C50, C51 150F-473K+P-AC CC 50V 0.047uF 10% 0603
C52 150F-222K+P-AC CC 50V 2200pF 10% 0603 0
C53, C54 15CH-150J+P-AC CTC 0/60 15pF 5% 0603
C55, C56, C57 157D-107M+K-LUTU CE 16V 100U 20% RLT
C58 157E-477M+K-S5TU CE 25V 470U 20% RLT
C59 150F-151J+P-AC CC 50V 150P 5% 0603
C6 150F-153J+P-AC CC 50V 0.015U 5% 0603
C60 150F-103J+P-AC CC 50V 0.01U 5% 0603
C61 157D-226M+K-IU CE 16V 22U 20% RLT 5x11
C62, C63 150F-471J+P-AC CC 50V 470P 5% 0603
C65 150F-104K+P-AC CC 50V 0.1uF 10%
C66 157D-107M+K-LUTU CE 16V 100U 20% RLT
C68 150F-104K+P-AC CC 50V 0.1uF 10%
C69 150F-100J+P-AC CC 50V 10P 5% 0603
C7 150F-682K+P-AC CC 50V 6800P 10%
C70 150F-100J+P-AC CC 50V 10P 5% 0603
C71 157D-476M+K-IU CE 16V 47U 20% RLT 5X11
C73, C74, C75 150F-104K+P-AC CC 50V 0.1uF 10%
C76, C77 150F-220K+P-AC CC 50V 22pF 10%
C78, C8, C80 150F-104K+P-AC CC 50V 0.1uF 10%
C83, C84 150F-102J+P-AC CC 50V 1000P 5% 0603 X7R
Location Part Number Description
