- 48 -
C85 150F-104K+P-AC CC 50V 0.1uF 10%
C86 157D-107M+K-IUI CE 16V 100UF 20% RLT
C89 157D-107M+K-LUTU CE 16V 100U 20% RLT
C9, C90 150F-104K+P-AC CC 50V 0.1uF 10%
C91 157D-107M+K-LUTU CE 16V 100U 20% RLT
C93 157D-476M+K-IU CE 16V 47U 20% RLT 5X11
C94 150F-104K+P-AC CC 50V 0.1uF 10%
C95 157D-107M+K-LUTU CE 16V 100U 20% RLT
C96 150F-104K+P-AC CC 50V 0.1uF 10%
DIODE
D2 4804-0070+2 DIODE IN4007-F AT
D3 4804-1480+2 DIODE 1N4148T AT
WAFER/SOCKET
J1 2102-030S+003 3P ST.WAFER P=2.0
J2 2101-3149+0 CONNECTOR FFC 15P P1.25
J5 2102-080S+003 8P ST. WAFER P=2.0
J7 2102-050S+003 5P ST. WAFER P=2.0
JP8 2102-040S+003 WAFER 4P P2.0 STRAIGHT
SW1 2101-0661+0 SHUNT 2P P=2.54
SW1 2101-1495+0 WAFER 3PIN P=2.54 ST 6MM
JACK/SOCKET
J4 2113-1837+0 NPLG-6P-134 25055150
CRYSTAL
X1 2300-0110+0 CRYSTAL 16.9344 MHZ
X5 2300-3306+0 CRYSTAL QUARTZ 32.768KHZ
X6 2300-3317+0 CRYSTAL 9.0MHZ +/-30PPM
TRANSISTOR
Q1 4858-56B0+3 TR BC856B SOT23 PHILIPS
Q2 4851-4570+5 TR PNP 2SB1457 TO-92 RL
Q3, Q4, Q6 4860-0700+K TR 2SC1815-GR(TE2/F/T) R
Q7 4852-668Y+U TR NPN 2SC2668 Y:100-200
RESISTOR
R1 4723-100J+P-R RMG 1/16W 10R 5% 0603
R12, R13, R14, R16, R17, R19, R20, R22, R27, R36,
R39, R41, R42, R45, R47, R48, R49, R52, R57, R58,
R59, R61, R66, R67, R69, R78, R79, R8, R80, R81,
R82, R83, R84, R85, R86, R87, R88, R89, R90, R91,
R92, R93, R94, R95
4723-103A+P-R RMG 1/16W 10K 1% 0603
Location Part Number Description
